Welding machine


Among industrial welding processes, orbital TIG welding has become a well-established method, although there is still a consider- able lack of information about the various possibilities of this challenging technique. Aerospace industry, aviation, high speed trains, nuclear industry, pharmaceutical industry, food industry, tiny microelectronic devices - to name but a few of the most exciting applications - rely on orbital weld- ing, but the equipment to ensure our daily supply of electric current, oil and gas also depends on orbital welding techniques.

In this booklet, basic information is pro- vided about the orbital weld process and the related equipment: technical approach, advantages, common and special applica- tions, but also restrictions and limits. To give practical examples, the text is illustrated by numerous application examples.

Tables and designs can help engineers and welding experts, as well as project managers, to get quick answers as to whether orbital welding could offer solutions corresponding to their needs. To get specific answers for your questions, visit the Polysoude website (www.polysoude.com) and consult the cus- tomer service team

Closed chamber welding head : UHP

  • UHP 625 Closed chamber welding head for welding of tube to tube joints, tube to micro-fitting joints…

    3 mm (0.12") ID
    17.2 mm (0.68") OD

  • UHP 500-2 Closed chamber welding head for welding of tube to tube joints, tube to micro-fitting joints…

    3 mm (0.12") ID
    12.7 mm (0.50") OD

  • UHP 250-2 Closed chamber welding head for welding of tube to tube joints, tube to micro-fitting joints…

    1.6 mm (0.06") ID
    6.35 mm (0.25") OD

Closed chamber welding head : MW

  • MW 65-3 Closed chamber welding head for welding of tube-to-tube joints

    6 mm (0.24") ID
    65 mm (2.56") OD

  • MW 34 Closed chamber welding head for welding of tube-to-tube joints

    6 mm (0.24") ID
    34 mm (1.34") OD

  • MW 170-2 Closed chamber welding head for welding of tube-to-tube joints

    80 mm (3.15") ID
    170 mm (6.69") OD

  • MW 115-3 Closed chamber welding head for welding of tube-to-tube joints

    12 mm (0.47") ID
    115 mm (4.53") OD

Open welding head : MU IV

  • MU IV 76/195 P Open welding head for welding of tube-to-tube joints, tube to elbow joints…

    76 mm (2.99") ID
    195 mm (7.68") OD

  • MU IV 8/38 P Open welding head for welding of tube-to-tube joints, tube to elbow joints…

    8 mm (0.31") ID
    38 mm (1.50") OD

  • MU IV 25/128 P Open welding head for welding of tube-to-tube joints, tube to elbow joints…

    42 mm (1.65") ID
    128 mm (5.04") OD

  • MU IV 25/115 P Open welding head for welding of tube-to-tube joints, tube to elbow joints…

    25 mm (0.98") ID
    115 mm (4.53") OD

  • MU IV 14/38 CW P Open welding head for welding of tube-to-tube joints, tube to elbow joints…

    19 mm (0.75") ID
    80 mm (3.15") OD

  • MU IV 114/275 P Open welding head for welding of tube-to-tube joints, tube to elbow joints…

    114 mm (4.49") ID
    275 mm (10.83") OD

"Low Profile" Open-type carriage welding head : POLYCAR

Open welding head : TS

  • TS 8/75 Open welding head for welding of tube-to-tubesheet joints

    8 mm (0.31") ID
    75 mm (2.95") OD

  • TS 34-2 Closed chamber welding head for welding of tube-to-tubesheet joints

    10 mm (0.39") ID
    33.7 mm (1.33") OD
